| MOQ: | 1-10 |
| Delivery Period: | 2 months |
| Payment Method: | L/C, T/T |
| Supply Capacity: | 99 |
| FANUC Robot SR-3iA | SR-3iA | |
| Controlled axes | 4 | |
| Max. payload at wrist | 3kg | |
| Motion range (X, Y) | 400mm, 800mm | |
| Stroke (Z) | 200mm | |
| Repeatability | J1 + J2 axis | ±0.01mm |
| J3 stroke | ±0.01mm | |
| J4 axis | ±0.004° | |
| Mass | 19kg | |
| Installation | Floor, Wall | |
| Matching controller / Input power source capacity | R-30iB Compact Plus / 2kVA | |
| Application | Handling, Assembling | |
FANUC Robot SR-3iA is SCARA robot whose payload is to 3kg.
The lightweight arm and the most advanced servo technology enable high accuracy and high duty performance. which improves the productivity.
Video
Video
|
|
| MOQ: | 1-10 |
| Delivery Period: | 2 months |
| Payment Method: | L/C, T/T |
| Supply Capacity: | 99 |
| FANUC Robot SR-3iA | SR-3iA | |
| Controlled axes | 4 | |
| Max. payload at wrist | 3kg | |
| Motion range (X, Y) | 400mm, 800mm | |
| Stroke (Z) | 200mm | |
| Repeatability | J1 + J2 axis | ±0.01mm |
| J3 stroke | ±0.01mm | |
| J4 axis | ±0.004° | |
| Mass | 19kg | |
| Installation | Floor, Wall | |
| Matching controller / Input power source capacity | R-30iB Compact Plus / 2kVA | |
| Application | Handling, Assembling | |
FANUC Robot SR-3iA is SCARA robot whose payload is to 3kg.
The lightweight arm and the most advanced servo technology enable high accuracy and high duty performance. which improves the productivity.
